TEST & MEASUREMENT FACILITY

Azista's highly equipped test and measurement equipment facility enhances the operation and precisely gives oriented outcome as per requirement. It is Facilitated with -

• - 100 Volts Programmable DC Power Supply
• Digital Multimeters
• High end Oscilloscope - DSO, MSO, MDO
• Waveform and Signal Generator
• Signal/Spectrum Analyzer
• Network Analyzer
• Electronics, Mechanical and Waveguide Calibration Kit
• Power Sensors
• Noise Source

Mixed Domain Oscilloscope

Bandwidth : 100 MHz Channels : 4 Analog 1 RF

EXA Signal Analyser

Frequency : 10 MHz to 43.5 GHz Amplitude Accuracy : ± 0.27 dB

Arbitrary Waveform Generator

2 Channel, 5GHz, 8GS/s

Waveguide Calibration Kit

Frequency : 3.2 to 40.0 GHz

EMI Receiver

Frequency : 3 Hz to 44 GHz Input Power : +30 dBm

Vector Network Analyzer

Frequency : 10 MHz to 43.5 GHz Harmonics Level : <-60 dBc

Digital Multimeter

Display Resolution : 6.5 Digits Measurements : V, A, F, Ω, Hz,

Microwave Analog Signal Generator

Frequency : 9 KHz to 31.8 GHz Harmonics Level : < -40 dBc

Lambda Power Supply

Voltage : 0-100 VDC Current : 0 A - 8 A

Electronic Calibration Module

Frequency: 18 MHz to 40 GHz

Spectrum Analyser

Frequency : 100 KHz - 12.4 GHz Accuracy : ±1 ppm

USB Average Power Sensor

Frequency : 10 MHz to 18 MHz Power Range : -35dBm to 20dBm

Digital Storage Oscilloscope

Bandwidth : 70 MHz Sample Rate : 1.0 GS/s

Arbitrary Waveform Generator

Max Frequency : 200 MHz Waveform length : 20 Mpts

Picoscope

Display Resolution : 6.5 Digits Measurements : V, A, F, Ω, Hz

RF Noise Source

Frequency : 10 MHz to 43.5 GHz
